Safety
Matched Components
and Specifications
| SINGLE
CHAIN SLINGS/TYPE S AND C |
Chain
Size
(Inches) |
Working
Load
Limit on
Straight
Lift in
Lbs.* |
Master
Links
Oblong
No. |
Master
Links
Oblong
Dia.
Material
"A"
Inches |
Master
Links
Oblong
Inside
Width
"B"
Inches |
Master
Links
Oblong
Inside
Length
"C"
Inches |
Hooks
Sling
No. |
Hooks
Grab
No. |
Coupling
Links
Use Same
Size as Chain
Actual
Material
Size In. |
Approx.
WT
5 Ft.
Reach
Type SOS |
| 7/32 |
2,100 |
HA 40 |
13/32 |
1-1/2 |
3 |
7/32 |
HA 7/32 |
1/4 |
3 lbs. |
| 9/32 |
3,500 |
HA 50 |
1/2 |
2-1/2 |
5 |
HA 220 |
HA 9/32 |
5/16 |
5 lbs. |
| 3/8 |
7,100 |
HA 75 |
3/4 |
2-3/4 |
5-1/2 |
HA 250 |
HA 3/8 |
7/16 |
9 lbs. |
| 1/2 |
12,000 |
HA 100 |
1 |
3-1/2 |
7 |
HA 280 |
HA 1/2 |
5/8 |
18 lbs. |
| 5/8 |
18,100 |
HA 100 |
1 |
3-1/2 |
7 |
HA 290 |
HA 5/8 |
3/4 |
27 lbs. |
| 3/4 |
28,300 |
HA 125 |
1-1/4 |
4-3/8 |
8-3/4 |
HA 300 |
HA 3/4 |
7/8 |
44 lbs. |
| 7/8 |
34,200 |
HA 150 |
1-1/2 |
5-1/4 |
10-1/2 |
HA 320 |
HA 7/8 |
1 |
58 lbs. |
| 1 |
47,700 |
HA 175 |
1-3/4 |
6 |
12 |
HA 330 |
HA 1 |
1-7/32 |
79 lbs. |
| 1-1/4 |
72,300 |
HA 200 |
2 |
7 |
14 |
HA 350 |
HA 1-1/4 |
1-15/32 |
121 lbs. |
| DOUBLE
CHAIN SLINGS/TYPE D |
Chain
Size
(Inches) |
Working
Load
Limit on
Straight
Lift in
Lbs.* |
Master
Links
Oblong
No. |
Master
Links
Oblong
Dia.
Material
"A"
Inches |
Master
Links
Oblong
Inside
Width
"B"
Inches |
Master
Links
Oblong
Inside
Length
"C"
Inches |
Hooks
Sling
No. |
Hooks
Grab
No. |
Coupling
Links
Use Same
Size as Chain
Actual
Material
Size In. |
Approx.
WT
5 Ft.
Reach
Type SOS |
| 7/32 |
3,600 |
HA 50 |
1/2 |
2-1/2 |
5 |
7/32 |
HA 7/32 |
- |
6 lbs. |
| 9/32 |
6,100 |
HA 50 |
1/2 |
2-1/2 |
5 |
HA 220 |
HA 9/32 |
5/16 |
10 lbs. |
| 3/8 |
12,300 |
HA 75 |
3/4 |
2-3/4 |
5-1/2 |
HA 250 |
HA 3/8 |
7/16 |
17 lbs. |
| 1/2 |
20,800 |
HA 100 |
1 |
3-1/2 |
7 |
HA 280 |
HA 1/2 |
5/8 |
32 lbs. |
| 5/8 |
31,300 |
HA 125 |
1-1/4 |
4-3/8 |
8-3/4 |
HA 290 |
HA 5/8 |
3/4 |
51 lbs. |
| 3/4 |
49,000 |
HA 150 |
1-1/2 |
5-1/4 |
10-1/2 |
HA 300 |
HA 3/4 |
7/8 |
74 lbs. |
| 7/8 |
59,200 |
HA 175 |
1-3/4 |
6 |
12 |
HA 320 |
HA 7/8 |
1 |
99 lbs. |
| 1 |
82,600 |
HA 200 |
2 |
7 |
14 |
HA 330 |
HA 1 |
1-7/32 |
134 lbs. |
| 1-1/4 |
125,200 |
HA 225 |
2-1/4 |
8 |
16 |
HA 350 |
HA 1-1/4 |
1-15/32 |
211 lbs. |
*
Caution: This working load limit should not be exceeded.
Special Hooks and Plate Clamp attachments available. |
